In the meantime, I'm apparently caught up in😉 the Star Wars universe: After my last two animatronic characters each had a Grogu, I have now ventured into another Star Wars character: A PIP repair droid from the series "The Acolyte".

This time, fortunately, I didn't come up with the idea three years after the hype, but discovered the character for myself in the first weeks of the series "The Acolyte" being broadcast.

A first video of my finished, animatronic PIP can be seen here:

Static Size and Color Double

This time, the first thing I did was build a static dummy to test and experiment with the size and colors of the droid. In particular, the question of how much mechanics can fit into the body is sometimes difficult to answer on the computer alone.

Assembling the dummy:

PIP Dummy

PIP Dummy

PIP Dummy

Construction

As with the Grogu I used a 3D printer again to make the parts for the droid. I acquired the basic 3D model from the 3D artist NerdRebelArt and modified it accordingly.

Actually, only the outer shape remains - inside everything has been supplemented by mechanics and holes, e.g. for screws and speakers.

PIP Dummy

PIP Dummy

PIP Dummy

Fortunately, my 3D printer can print with several colors at the same time, so I was able to print the droid's orange and blue colors directly. This saves me the later painting or gluing together of several parts.

PIP Dummy

Body

I divided the droid's body into two parts: The primary body, which contains most of the components, and a front panel, which only carries the keypad including RGB LEDs. Both are held together with 3mm screws and welded-in threaded inserts.

PIP Dummy

For the right "used look", the 3D printed parts still have to be sanded and aged. To do this, I applied thin black paint to all the recesses with a brush and then roughly wiped it off again. This will leave the paint only in the recesses and make the droid look "worn". A few added scratches and scuffs complete the picture.

PIP used look

There is not a single cm³ left in the body - everything is crammed with electronics and mechanics.

These are in detail:

  1. An ESP32 that takes control
  2. YX5300 UART Serial MP3 Player Module that plays the sounds
  3. Mini PAM8403 Stereo Amplifier , which amplifies the sounds
  4. 8 Ohm 3 Watt Speaker , which reproduces the sounds
  5. An uninterrupted charging module that charges the battery
  6. 18650 Li-ion battery supplying the voltage
  7. Switch to turn the droid on and off
  8. RGB LEDs and buttons
  9. Spring Contacts for Power Supply
  10. Mechanics for the servos
  11. Servos for the neck movements left/right and up/down

PIP Body Parts

PIP Body Parts

PIP Body Parts

Unfortunately, there is also no space left in the head, otherwise I would have liked to have installed a small pump so that PIP can spray liquids from its antenna as in the series. But I would have had to sacrifice the movement of the ear, which can be used more often and more sensibly in comparison. I had also prepared a small mechanism to spray sparks, but unfortunately I couldn't find a place for it.

PIP Neck and Servos

PIP Neck and Servos

In total, the following are built into the head:

  1. Servo for the rotation of the ear
  2. Servo for the tilt of the head up/down
  3. RGB LEDs for the "eyes"
  4. Mechanism for tilting the head with ball bearings and cable routing

Mechanics

The PIP droid has 4 servos and is responsible for the following movements:

  1. Turn head left/right
  2. Extend/retract neck
  3. Tilt your head up/down
  4. Rotate the left "ear"

I used serial servos for this, as they can be wired in a star shape and so only one cable for both servos leads to the controller through the thin neck. I first used Feetech SCS2332 Servos as the type, but later switched to the identical model STS3032, because the STS variant also supports acceleration and so the movements seem smoother.

The neck consists of an aluminum rod that is guided in a 3D-printed housing. There are two ball bearings in the head that guide the rod and another ball bearing in the body.

PIP Neck and Servos

PIP Neck and Servos

PIP Neck and Servos

PIP Neck and Servos

Key field

In front of the PIP droid sits a keypad consisting of four buttons. I would have liked to use a button that you can press correctly. But after subtracting the mechanics and the electronics, I have too little space in the belly of the droid if I also want to illuminate the keys. That's why I decided to make the buttons react to touch. Fortunately, the ESP32 already has touch pins that I can use for this.

PIP Body Parts

Visually, this is noticeable by the fact that a thin wire is installed in front of each key.

PIP Body Parts

PIP Body Parts

Software

As software for controlling the PIP, I use (as with the Grogu) my open source software Animatronic WorkBench.

Electronic components

Of course, there is a lot of electronics in the PIP. Before installation, I tested and programmed the components on a breadboard.

PIP Electronics

Finding a small but powerful speaker was not easy. In the end, I chose this 8 ohm 3 watt speaker that fits in the droid's head.

As an MP3 player, I have (as with the Grogu uses a YX5300 UART Serial MP3 Player Module . This can be controlled via a serial interface and plays MP3 files from a micro SD card. This time, too, a Mini PAM8403 Stereo Amplifier serves as an amplifier.

Power supply

Inside the PIP droid is a 18650 Li-Ion battery , which is charged via an uninterrupted charging module . Therefore, all components are operated with 5 volts, although the servos could be operated with up to 6 volts and would then have more power and speed.

The connection for the 5 volt voltage is made via spring contacts .

Pinout of the ESP32

ESP32 PIN Component PIN Component
GPIO17 RXD MP3 Player
GPIO16 TXD MP3 Player
GND GND MP3 Player
5V VCC MP3 Player
GPIO18 RXD SCS Servos Bus
GPIO19 TXD SCS Servos Bus
GND GND SCS Servos Bus
GPIO22 SLC i²c Bus
GPIO21 SDA i²c Bus
3.3V VCC i²c Bus
GND GND i²c Bus
5V 5V out via Schottky diode Voltage Source
GND GND Voltage Source
GPIO14 Front Pushbutton 1
GPIO27 Front Pushbutton 2
GPIO33 Front Pushbutton 3
GPIO32 Front Pushbutton 4
GPIO12 Hand Holder Back
GPIO34 per 220 Ohm to 5V Docking Detect when docked

Bag and docking station

For transport and storage, I sewed a bag that also serves as a docking station.

PIP Pouch

PIP Pouch

The bag has a USB port and can be operated with a power bank, which is in your trouser pocket, for example.

PIP Pouch

The docking station also has a USB port and can be operated with a power bank.

PIP Docking

For easy charging on the go, there is also a small USB adapter that can also be magnetically snapped to the bottom of the PIP droid.

PIP Docking

Teething troubles

The amplifier seems to overwhelm the power supply with its 3 watts when you turn up the volume. Then there is a complete voltage drop and the ESP32 restarts completely.

In the oscilloscope you can see very well that the voltage drops completely.

PIP Droid am Oszilloskop

Therefore, I initially limited the amplifier to about 50% volume by means of a resistor, which is still loud enough. At even higher volumes, the small speaker has started to distort anyway.

There were also problems with the head servos at the beginning, as the head jerked slightly when turning left/right, for example. At first I thought that the servos were too weak, but in fact the problem went away directly when I held the neck a bit and made it rather heavier. My current assumption is that the motion is rocking up in a kind of wave due to an unfortunate interplay of the inertia of the head and the exact acceleration. Currently I solve this by damping the neck with a piece of foam rubber that I put in the neck and adjusting the specific rotation speed. Because a little faster or slower works fine again.
