Gaito

A holographic desktop assistant

>> Download all 3d models as STL files for your 3d printer


First tries to find out the best position for the Philips Pico Pix 4010 LED-Projector , the acrylic plate and the mirror - using Makerbeam parts.


3d printing the final mount.


First test for the beamer and mirror mount.


The base plattform, designed for 3d printing.


The 3d printed base plattform, including 4 Makerbeam parts and two of 8x8 neopixel boards .


Tests for the projection sizes on the acrylic tube - simulated by a sheet of paper.


Assembled prototype 1 including bended acrylic foils and a projection plate insite the tube. The 3d printed housing for beamer and mirror is added, too.


First tests with prototype 1.


Version 2 used a more stable acrylic tube instead of foils.


The assembled prototype 2


The raspberry pi on the left controls the neopixel and a additional beamer fan.


Testing the neopixel board in white/blue...


... and red color.


Final test for prototype 2.


The second prototype is completed.
